How to build an optical fiber network by lowering the total system cost

Speed of deployment, cost of right-of-way access, logistics cost and turn-up time all have an impact on the overall cost to build an optical fiber network. Take advantage of all of these.

LaserFousWorld Test
LaserFousWorld Test

As fiber optic access networks begin to proliferate, more operating companies will begin to deploy optical fiber cable in various configurations to the last mile. Key technology requirements in fiber optic cable designs are being identified to lower the average build cost per subscriber. In fiber-to-the home (FTTH), fiber to the node (FTTN) or any fiber optic access (FTTx) type topologies, the same cost issues are prevalent as in traditional outside plant (OSP) point to point builds. Speed of deployment, cost of right-of-way access, logistics cost, and turn-up time all have an impact on the overall cost to build an optical fiber network.


Traditional OSP cable designs utilize either a loose buffer core or ribbon core cable design. Limitations of these cable designs are most impacted by the fiber density and core configurations. In most cases, the system designer will use ribbon cables in the higher fiber counts above 144 fibers, and use loose tube cables in fiber counts below 144 fibers. Fiber optic cable is deployed this way to optimize utilization of the aerial or underground rights-of-way, and to get the advantages of splicing efficiency in high-fiber count reel-end splicing versus mid-cable access splicing in the distribution or access part of the network. The traditional cable technologies of standard ribbon fiber optic cable and loose tube fiber optic cable have design and application limitations that make them counterproductive when considered for both feeder (F1) and distribution (F2) portions of FTTx networks.


AFL’s Wrapping Tube Cable (WTC) which utilizes Spider Web Ribbon (SWR) will be compared to traditional ribbon and loose tube cable technologies to look at cable performance comparisons to industry standards to demonstrate that WTC cable is consistent with industry requirements and customer handling needs. You will also see how Wrapping Tube Cable was developed to address the design and application limitations of traditional loose tube and ribbon fiber optic cables by getting the best attributes of each technology. By having an extremely high fiber density, the WTC cable diameter and weight is much lower than traditional loose tube or ribbon fiber optic cable. This significantly improves installation speed and efficiency. With the WTC cable having a dry core technology, and the ability to mass fusion splice or single fiber splice, the cable is more efficient in reel-end splicing time or mid-cable access time. Additional savings are also found in reduced hand-hole sizes, splice closures sizes, and logistic cost.

Get the white paper here
