HDMI Install Test Kits for Gold-Plated Subs

Atlona Technologies released three custom installation test kits designed to diagnose 99% of all digital connectivity issues with HDMI. The AT-KIT-HD1, AT-KIT-PROHD2, and AT-KIT-PROHD3 kits combine an HDMI signal generator and seven-inch HDMI monitor in a Pelica...

Content Dam Btr Migrated 2011 01 Atlona At Kit Prohd3
Atlona At Kit Prohd3Atlona Technologies released three custom installation test kits designed to diagnose 99% of all digital connectivity issues with HDMI. The AT-KIT-HD1, AT-KIT-PROHD2, and AT-KIT-PROHD3 kits combine an HDMI signal generator and seven-inch HDMI monitor in a Pelican case, while the AT-KIT-PROHD3 also features the AT-HDSync HDMI EDID emulator and AT-BAT-DIS7PRO monitor battery.

All three kits include Atlona's AT-HD800 portable HDMI signal generator. The AT-HD800 allows users to diagnose specific resolution, video timing, EDID, and color space issues in any DVI or HDMI video system. It features 13 test patterns, including 3D tests side by side, top and bottom, and frame packing for HDMI 1.4 devices. It features an HDMI output as well as an HDMI pass-through.

The AT-DIS7-HD is a seven-inch testing monitor that recognizes any HDMI or DVI source at resolutions up to 1080p, and allows users to observe both audio and video signals in real time. The compact display allows users to view signal information such as HDCP compliance, resolution, frequency, digital format, and audio information. The AT-DIS7-PROHD seven-inch testing monitor recognizes any HDMI, DVI, VGA, or component video source at resolutions up to 1080p or 1920x1200. The AT-DIS7-PROHD can also be used to test 3D sources.

The AT-BAT-DIS7PRO is a five-hour monitor battery. The AT-HDSync HDMI EDID emulator is intended for fixing any EDID, hot plug, or sync issue. It stores the EDID information and recalls a default EDID setting in non-volatile memory that supports HDCP handshaking. The device can also generate a missing hot plug, and will stay in line to maintain the hot plug.
